| Model | XCX-905 | ||||||
| Power supply | AC 220 V/ (50 - 60 Hz) | ||||||
| Size | 470*465*350mm | ||||||
| Machine weight | 35KG | ||||||
| Stripping length (outer sheath end ) | 1 - 60mm | ||||||
| Stripping length (out sheath tail) | 1 - 30 mm | ||||||
| Stripping length (core wire end ) | 1 - 20 mm | ||||||
| Stripping length (core wire tail) | 1 - 20 mm | ||||||
| Total machine power | 680w | ||||||
| Rated power | 400w | ||||||
| Working speed | 600-1000pcs/h | ||||||
| Core wire cutting | 2-5core | ||||||
| Cutting length | 0.1-999999.99mm | ||||||
| Blade material | Imported high speed steel | ||||||
| Wire stripping precision | 0.01 mm (silent hybrid stepper motor) | ||||||
| Program storage | No. 00–99 | ||||||
| Display mode | 4.3-inch touch screen | ||||||
| Working air pressure | 0.5-0.8Mpa | ||||||
| Auxiliary functions | Automatic wire feeding/leading, timer start, jog adjustment | ||||||
Q:What are your terms of delivery?
A:EXW. FOB CFR. CIF
Q:Do you test all your goods before delivery?
A:Yes, we have 100% test before delivery.
Q:How do you pack the products ?
A:All machines we manufacture and sell are packed with wooden box,cover with steel tie on its surface to avoid damage during delivery.
Q:What is your terms of payment?
A:T/T 50% as deposit, and 50% before delivery,We will show you the photos of the products and packages before you pay the balance.
Q:Do your product have warranty and refund or return?
A:Yes, All our products have one year warranty and no reason refund within 7 days after customer received product( Customer need to pay for the Return shipping fee )
Q:Can you Xingchuangxin provide spare parts and maintenance?
A:For the products within warranty period,we will provide the spare parts to repair for free.
Technical support is always provided during your daily using and maintenance.
Q:Are you Xingchuangxin a trader or a factory?
A:We are a professional manufacturer of wire stripping machines,cutting machines in China for 12 years.
